BDS Suspension Chevrolet/GMC 4WD 7" Lift Kit for 01-10 2500 HD Silverado/Sierra 3/4 ton pickup - 189H

(0) Reviews: Write first review
BDS189H
Pricing: $2,290.11

Customize Your Item

- Rear Lift Kit Upgrades: -
 * required
- Track Width Option -
 * required
- Shock Boot Selection -
 * required
- Optional Accessories & Upgrades -
 * required
- Shock Options -
 * required
- Traction Bars -
 * required
- Steering Stabilizer -
 * required
Qty:
Free Shipping

Description

This unique High Clearance suspension lift kit utilizes high arched crossmembers that blend perfectly with the angle of the factory installed lower control arms for a completely integrated look while lifting your vehicle a full 7"dramatically increasing ground clearance at the front crossmembers and improving operating geometry. Torsion bars are mounted directly to the top of the lower a-arm eliminating the need to drop the torsion bar crossmember.

A front skid plate and differential skid plate come standard, to lock everything together, creating a nearly indestructible sub frame for extreme off road protection.

The rear is lifted with a flat 5" block for easy installation. Upgrade to Glide-Ride Leaf Springs for reduced axle wrap and more control while towing.

This highly customizable kit gives you the choices you need to build your rig your way. With standard or narrow track knuckles, gas shocks and dual steering stabilizers as just a few of the options and upgrades available for this 7" Chevy/GMC suspension lift kit.

Features

  • Important Kit Notes

    • 1. Torsion Bar tool required to load/unload the torsion bars.
    • 2. Some welding required.
    • 3. Requires frame bracket modification and differential mount modification.
    • 4. Traction bars will not fit standard cab/short box models and are designed to work on vehicles with 4" to 8" of lift.
    • 5. 20" wheels with 5" to 5-3/4" backspacing recommended to reduce trimming.
    • 6. Gas models require exhaust modification.
    • 7. Narrow track knuckle will slightly increase turning radius.
    • 8. For tail high stance use #119157 add-a-leaf with the block kit or #069207 with leaf spring kit.
    • 9. Dually applications will require custom u-bolts.

    • Manufacturer Notes

    BDS Suspension Lift Kit Warranty

    No Fine Print Warranty

    All BDS Suspension lift kits come with the security of knowing you purchased the finest lift kit in the aftermarket suspension industry. We back our commitment to engineering reliable, quality 4x4 off-road Jeep and truck suspension products with our unique "No BS Hardcore Lifetime Warranty".

    If you are the original purchaser of any BDS lift kit and it breaks, we will give you a new part. Period.

    Tire & Wheel Combinations

    2001-2007 Classic Body Style

    35" x 12.50" w/16 x 8 and 4-1/2" back spacing

    35" x 12.50" w/17 or 18 x 9 and 5.5" back spacing

    37" x 12.50" w/20 x 9 and 5.75" back spacing

    2007-2010 New Body Style

    35" x 12.50" w/16 x 8 and 4-1/2" back spacing

    35" x 12.50" w/17 or 18 x 9 and 5.5" back spacing

    35" x 12.50" w/20 x 9 and 5.75" back spacing

    • Tire & Wheel Combinations
    • Est. Installation: 8-10 hours
    • Difficulty Level (easy 1 - 5 complicated): 4

    Vehicle Fitment Information

    • 2001 Chevy / GMC 1 Ton Pickup 4WD
    • 2002 Chevy / GMC 1 Ton Pickup 4WD
    • 2003 Chevy / GMC 1 Ton Pickup 4WD
    • 2004 Chevy / GMC 1 Ton Pickup 4WD
    • 2005 Chevy / GMC 1 Ton Pickup 4WD
    • 2006 Chevy / GMC 1 Ton Pickup 4WD
    • 2007 Chevy / GMC 1 Ton Pickup 4WD
    • 2008 Chevy / GMC 1 Ton Pickup 4WD
    • 2009 Chevy / GMC 1 Ton Pickup 4WD
    • 2010 Chevy / GMC 1 Ton Pickup 4WD
    • 2001 Chevy / GMC 3/4 Ton Pickup 4WD 2500 HD
    • 2002 Chevy / GMC 3/4 Ton Pickup 4WD 2500 HD
    • 2003 Chevy / GMC 3/4 Ton Pickup 4WD 2500 HD
    • 2004 Chevy / GMC 3/4 Ton Pickup 4WD 2500 HD
    • 2005 Chevy / GMC 3/4 Ton Pickup 4WD 2500 HD
    • 2006 Chevy / GMC 3/4 Ton Pickup 4WD 2500 HD
    • 2007 Chevy / GMC 3/4 Ton Pickup 4WD 2500 HD
    • 2008 Chevy / GMC 3/4 Ton Pickup 4WD 2500 HD
    • 2009 Chevy / GMC 3/4 Ton Pickup 4WD 2500 HD
    • 2010 Chevy / GMC 3/4 Ton Pickup 4WD 2500 HD
