Vision X 2" SOLSTICE SOLO BLACK 10W LED 10, 30, 60 OR ELLIPTICAL      -XIL-S

VIS-XIL-S
The Solstice Series uses 10-watt LEDs to achieve the highest light output for the housing. The Solstice S1100 Solo is 900 lumens of light in a 2"x2" package for tons of light mountable in the smallest spaces
Pricing: $99.00

Customize Your Item

- Choose Degree/Beam -
 * required
Qty:
Free Shipping

Description

Why
Solstice
The Solstice Series
uses 10-watt LEDs to achieve the highest light output for the housing. The
Solstice S1100 Solo is 900 lumens of light in a 2""x2"" package for
tons of light mountable in the smallest spaces

Prime
Drive - The Smart LED Pod

Electronic
Thermal Management


ETM monitors the heat output of the LEDs and makes use of
integrated Pulse Width Modulation circuitry in order to maintain safe operating
temperatures in order to prolong the LED life span to its full 50,000 hour
potential.

Pulse Width Modulation

The Solstice Solo utilizes integrated Pulse Width
Modulation (PWM) dimming circuitry to manage heat levels. PWM works by flashing
the LED at a frequency faster than the human eye can detect, reducing the time
that the LED is operating while still delivering 100% light output.


Efficient Circuitry

The Solstice
Solo is driven to 90% efficiency for less wasted energy and more light output.


Pure Optics

With 90% optically pure Vision X optics, you can be sure that
you are getting the most distance and most accuracy out of each LED.

Lightweight
and Compact

Die-Cast
Aluminum Housing


The Solstice Solo has a die-cast aluminum weighing only .4
pounds.


IP-68 Rated

The Solstice Solo has achieved an ingress
protection rating of IP-68, signifying that it is dust-proof and submersible in
water up to 3 meters.


Proven Mounting System

The Solstice Solo uses a single-stud mount
system that allows for adjustability.

"

Features

  • KEY FEATURES

    Less than 1 amp Power Consumption
    High Output 2" Square Compact Design
    88% Optically Pure
    Mounting and Application Accessories Available
  • System Contents

  • Solstice Solo LED

  • Light
  • • Wiring Pigtail
  • • Installation Instructions
  • • Adjustment Allen Wrench

  • Manufacturer Notes

    SPECIFICATIONS

    WARRANTY

    Extended

    AVAILABLE HOUSING COLOR

    Black or White

    LED LIFESPAN

    50,000

    TECHNICAL DETAILS

    OPTIC PURITY

    88%

    DRIVEN AT

    80%

    INPUT VOLTAGE

    9-48V DC

    IP RATING

    IP-68

    VIBRATION RATING

    15.6G

    OPERATING TEMPERATURE

    -40 Celsius ~ +80 Celsius

    ADDED FEATURES

    • Weatherproof Deutsch Connector with Plug-and-Play Harness
    • Compatible with Select Solo Pod Accesories
    • Die-Cast Aluminum Housing
    • Polycarbonate lens
    • Pat. Pending
